| TYSON |  |
| BREED | : | SB |
| AGE | : | Unknown |
| HEIGHT | : | 17 hh |
|
COMMENTS
Tyson's heels are extremely under run, which has resulted in incorrect weight distribution and an excessively long toe. The after photos do not show a perfect hoof, however with more frequent trimming, they are well on their way to becoming strong, healthy and well functioning. |
 |
|
 |
 |
Before 1st Corrective Trim
Left Front - Side View
13.06.09 |
|
After 1st Corrective Trim
Left Front - Side View
13.06.09 |
|
 |
|
 |
|
Before 1st Corrective Trim
Left Front - Underneath View
13.06.09 |
|
After 1st Corrective Trim
Left Front - Underneath View
13.06.09 |
|
Under run heels - observation
The tendency for forward (rather than upward) hoof growth, along with incorrect or infrequent trimming has resulted in heels that have migrated too far forward, with downward force being concentrated in an area which has no support. (yellow arrows)
Action taken
By applying correct trimming techniques, heel support has been created as much as possible, and over time more upright growth will be encouraged.
|
Long toes - observation
The toes are too long from either incorrect or infrequent trimming. Break over becomes difficult and excess force is placed on the toe area of the hoof resulting in compromised wall/laminar connection.
Action taken
The excess toe has been removed as much as possible and a mustang roll applied according to the thickness of hoof wall. Leverage forces are removed, thus facilitating a tight wall/laminar connection.
|
Frog contracted - observation
No ground stimulation has contributed to atrophy and contraction of the frog and heel bulbs. The force of impact is diverted to other areas which are not designed as shock absorbing structures.
Action taken
Removal of the cause encourages the hoof to function correctly, thereby activating long unused parts of the hoof. Over time the frog and heel bulbs will open out, expand and become functional shock absorbing structures of the hoof.
|
